Name: Allied Telesis FS710/5E Unmanaged Fast Ethernet (10/100) Green, Grey AT-FS710/5E-60
Brand: Allied Telesis
SKU: AT-FS710/5E-60
Price: 119.87 CAD
Availability: InStock

888-370-2261 info@itlogixs.ca 157 Edith Way NW, Calgary, AB, T3R 2B8

Home /Networking & Communications /Network Switches /Allied Telesis FS710/5E Unmanaged Fast Ethernet (10/100) Green, Grey

Product Details

The Allied Telesis FS710 Series is the economical and eco-friendly solution for today’s networks, providing an extensive range of cost-effective options.

The FS710 Series switches providesilent operation, with easy set-upand simple connectivity for desktop and small to medium network environments.

High performance
Full auto-negotiating 10/100 ports allow FS710 switches to detect the speed and duplex modes of attached devices, and automatically configure for the best possible performance.

Quality and reliability
Allied Telesis is a world-wide leader in unmanaged Ethernet switches. Shipping more than 250,000 unmanaged switches every year, Allied Telesis offers proven reliability, and
industry-recognized quality.

Product Specifications

Manufacturer	Allied Telesis
Manufacturer Part Number	AT-FS710/5E-60
GTIN / Barcode	0767035211756
Brand Name	Allied Telesis
Product Name	Allied Telesis FS710/5E Unmanaged Fast Ethernet (10/100) Green, Grey

Management features
Mfr. Part Number	AT-FS710/5E-60
GTIN / Barcode	0767035211756
Switch type	Unmanaged
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	5
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Network
Networking standards	IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
10G support	No
Full duplex	Yes
Auto MDI/MDI-X	Yes
Auto-negotiation	Yes
Data transmission
Switching capacity	1 Gbit/s
Throughput	0.74 Mpps
MAC address table	2000 entries
Jumbo frames support	Yes
Jumbo frames	2048
Packet buffer memory	0.096 MB
Design
Rack mounting	No
Product colour	Green, Grey
LED indicators	Activity, Link, Power
Wall mountable	Yes
Safety	UL60950-1, CSAC22.2 №60950-1, EN60950-1(TUV), CE
Power
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1.7 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)	No
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-20 - 70 °C
Operating relative humidity (H-H)	5 - 90%
Storage relative humidity (H-H)	5 - 95%
Weight & dimensions
Width	131 mm
Depth	101 mm
Height	30 mm
Weight	380 g
Certificates
Certification	VCCI Class B FCC Class B EN55032 Class A CISPR 32 Class B RCM Class B
Logistics data
Harmonized System (HS) code	85176990
Brand	Allied Telesis
Availability	In Stock
Price Currency	CAD
Category	Network Switches
