ATEN USB VGA KVM Extender with Audio and RS-232 (200m) CE750A
CA$604.99
Save 5%
CA$575.76
CAD
Prices shown in CAD. Taxes, duties and freight are quoted separately. Call 888-370-2261 for volume pricing.
- B2B Volume Pricing in CAD
- Purchase Orders Accepted for Approved Accounts
- Canada-Wide Business & Institutional Purchasing
- Secure Checkout & Reliable Canada-Wide Delivery
Product Details
The CE750A is a USB-based KVM Extender with automatic signal compensation and RS-232 serial functionality that allows access to a computer system from a remote USB console (USB keyboard, monitor, and USB mouse).
Because it allows access to a computer system from a remote console, the CE750A is perfect for use in any type of installation where you need to place the console where it is conveniently accessible, but you want the system equipment to reside in a safe location – for example away from the dust and dirt of the factory floor or the harsh environment of a construction site.
The CE750A improves on previous designs by the addition of an RS-232 port, on both the Local and Remote Units, that allows you to connect to a serial terminal for configuration (Local Unit) or serial devices such as touchscreens and barcode scanners (Remote Unit).
Because it allows access to a computer system from a remote console, the CE750A is perfect for use in any type of installation where you need to place the console where it is conveniently accessible, but you want the system equipment to reside in a safe location – for example away from the dust and dirt of the factory floor or the harsh environment of a construction site.
The CE750A improves on previous designs by the addition of an RS-232 port, on both the Local and Remote Units, that allows you to connect to a serial terminal for configuration (Local Unit) or serial devices such as touchscreens and barcode scanners (Remote Unit).
Product Specifications
| Manufacturer | ATEN |
|---|---|
| Manufacturer Part Number | CE750A |
| GTIN / Barcode | 0672792006852 |
| Brand Name | ATEN |
| Product Name | ATEN USB VGA KVM Extender with Audio and RS-232 (200m) |
| Mfr. Part Number | CE750A |
|---|---|
| GTIN / Barcode | 0672792006852 |
| Features | |
| Type | Transmitter & receiver |
| Connectivity technology | Wired |
| Maximum transfer distance | 200 m |
| Cable types supported | Cat5 |
| Maximum digital resolution | 1920 x 1200 pixels |
| KVM port selection | Push-buttons |
| Product colour | Black |
| Material | Metal |
| Certification | RoHS |
| Transmitter | |
| Transmitter local video port type | VGA |
| Transmitter local keyboard/mouse port type | USB |
| Receiver | |
| Receiver local video port type | VGA |
| Receiver local keyboard/mouse port type | USB |
| Weight & dimensions | |
| Transmitter width | 8.63 cm |
| Transmitter depth | 20.2 cm |
| Transmitter height | 2.5 cm |
| Transmitter weight | 470 g |
| Receiver width | 8.51 cm |
| Receiver depth | 20.2 cm |
| Receiver height | 2.5 cm |
| Receiver weight | 470 g |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Brand | ATEN |
| Availability | In Stock |
| Price Currency | CAD |
| Category | Cables & Connectivity |
