ATEN VE813A AV extender transmitter & receiver Black
CA$1,228.99
Save 5%
CA$1,170.68
CAD
Prices shown in CAD. Taxes, duties and freight are quoted separately. Call 888-370-2261 for volume pricing.
- B2B Volume Pricing in CAD
- Purchase Orders Accepted for Approved Accounts
- Canada-Wide Business & Institutional Purchasing
- Secure Checkout & Reliable Canada-Wide Delivery
Product Details
The VE813A HDMI HDBaseT Extender is an HDMI and USB Extender that supports HDBaseT and patented ExtremeUSB® technology. The VE813A can extend HDMI and USB 2.0 signal up to 100 meters from the HDMI source using a single Ethernet cable. The VE813A supports HDMI features such as 3D, Deep Color, 4K, CEC and HDCP. It is equipped with USB connectors that provide touch panel control and file transfer functionality. The extender is also great for synchronizing files and folders between portable and desktop computers. The superior display capability makes VE813A ideal for medical imaging and digital signage.
Product Specifications
| Manufacturer | ATEN |
|---|---|
| Manufacturer Part Number | VE813A |
| GTIN / Barcode | 0672792007156 |
| Brand Name | ATEN |
| Product Name | ATEN VE813A AV extender AV transmitter & receiver Black |
| Mfr. Part Number | VE813A |
|---|---|
| GTIN / Barcode | 0672792007156 |
| Features | |
| Type | AV transmitter & receiver |
| Cable types supported | Cat5e, Cat6, Cat6a, Cat7 |
| Maximum transfer distance | 100 m |
| LED indicators | Yes |
| Supported video modes | 1080p, 2160p |
| Bandwidth | 10.2 Gbit/s |
| Bandwidth | 340 MHz |
| HDCP | Yes |
| Material | Metal |
| 3D | Yes |
| Consumer Electronics Control (CEC) support | Yes |
| Impedance | 100 Ω |
| Product colour | Black |
| Ports & interfaces | |
| Connectivity technology | Wired |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
| Number of HDMI outputs | 1 |
| USB ports quantity | 4 |
| USB version | 2.0 |
| USB connector type | USB Type-A, USB Type-B |
| DC-in jack | Yes |
| Power | |
| Operating voltage (transmitter) | 5 V |
| Operating voltage (receiver) | 5 V |
| Power consumption (typical) | 5.75 W |
| Power consumption (receiver) (max) | 13.25 W |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Weight & dimensions | |
| Dimensions (WxDxH) | 117.9 x 182 x 28.7 mm |
| Weight | 1.23 kg |
| Packaging content | |
| AC adapter included | Yes |
| Cables included | HDMI, USB |
| Mounting kit | Yes |
| Logistics data | |
| Products per master (outer) case | 5 pc(s) |
| Brand | ATEN |
| Availability | In Stock |
| Price Currency | CAD |
| Category | Computers & IT Hardware |
