ATEN
ATEN Rack mount kit for The Presentation Matrix Switch (VP); 2x Mounting Brackets
Mfr. Part# 2X043G
CA$32.99
CA$31.46
ATEN
ATEN VM0808HB video switch HDMI
CA$2,849.99
Save 5%
CA$2,714.03
CAD
Prices shown in CAD. Taxes, duties and freight are quoted separately. Call 888-370-2261 for volume pricing.
- B2B Volume Pricing in CAD
- Purchase Orders Accepted for Approved Accounts
- Canada-Wide Business & Institutional Purchasing
- Secure Checkout & Reliable Canada-Wide Delivery
Product Details
ATEN’s VM0808HB is a True 4K HDMI Matrix Switch series that offers an easy and affordable way to route any of 8 HDMI video sources to any of 8 HDMI displays. Featured with the superior video resolutions up to 4096 x 2160 @ 60Hz (4:4:4), the VM0808HB delivers robust signal routing and ultra-fast digital video switching, making it perfect for applications where routing of True 4K digital signals is required, such as event venues, digital classrooms, auditoriums, department stores, and more.
The intuitive GUI design of the VM0808HB allows users to flexibly configure any input to output connections, eliminating the need of frequent physical configuration changes. In addition to the built-in web GUI, the VM0808HB can be operated through front-panel pushbuttons, IR remote, RS-232 control, and Telnet via Ethernet connections, giving users the ultimate convenience while keeping the system available with performance video switching anytime.
The intuitive GUI design of the VM0808HB allows users to flexibly configure any input to output connections, eliminating the need of frequent physical configuration changes. In addition to the built-in web GUI, the VM0808HB can be operated through front-panel pushbuttons, IR remote, RS-232 control, and Telnet via Ethernet connections, giving users the ultimate convenience while keeping the system available with performance video switching anytime.
Product Specifications
| Manufacturer | ATEN |
|---|---|
| Manufacturer Part Number | VM0808HB |
| GTIN / Barcode | 0672792008795 |
| Brand Name | ATEN |
| Product Name | ATEN VM0808HB video switch HDMI |
| Mfr. Part Number | VM0808HB |
|---|---|
| GTIN / Barcode | 0672792008795 |
| Ports & interfaces | |
| Video port type | HDMI |
| HDMI in | 8 |
| Number of HDMI outputs | 8 |
| RJ-45 input ports | 1 |
| RS-232 ports | 1 |
| Features | |
| Material | Metal |
| Product colour | Black |
| HDCP | Yes |
| Maximum operating distance | 15 m |
| Bandwidth | 600 MHz |
| Maximum resolution | 4096 x 2160 pixels |
| 3D | Yes |
| HD type | 4K Ultra HD |
| Rack capacity | 1U |
| Input impedance | 100 Ω |
| Output impedance | 100 Ω |
| Power | |
| AC adapter input voltage | 100-240 V |
| AC adapter frequency | 50-60 Hz |
| AC adapter input current | 1 A |
| Weight & dimensions | |
| Width | 432.4 mm |
| Depth | 262.3 mm |
| Height | 44 mm |
| Weight | 3.99 kg |
| Packaging content | |
| Remote control included | Yes |
| User guide | Yes |
| Cables included | AC |
| Mounting brackets included | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Brand | ATEN |
| Availability | In Stock |
| Price Currency | CAD |
| Category | Network Switches |
