Brainboxes
Brainboxes Ethernet 4 Port RS232 ES-701
CA$633.99
Save 5%
CA$604.01
CAD
Prices shown in CAD. Taxes, duties and freight are quoted separately. Call 888-370-2261 for volume pricing.
- B2B Volume Pricing in CAD
- Purchase Orders Accepted for Approved Accounts
- Canada-Wide Business & Institutional Purchasing
- Secure Checkout & Reliable Canada-Wide Delivery
Product Details
Ethernet to Serial device server providing access to four RS232 serial port. Data transfer rates up to 1,000,000 baud rates (1 MegaBaud), coupled with 1Mbit/s line drivers deliver uncompromising performance. Baud rates can be standard values such as 9,600, 115,200, 230,000, 921,600 or user definable non standard values.Our ES range provides simple instant networked serial ports. A web interface allows secure configuration and control of the serial ports over a local network or the internet using any browser. For Windows our in-house designed (32 bit and 64 bit) driver gives you local COM ports, retaining existing software applications and allowing you to connect across your network to remote devices just as if they were attached locally. Serial Port Tunnelling (individually configurable) allows serial cable replacement over any distance, no software required. You can access the device via TCP/IP sockets from any networked device like an Android tablet, PC or phone. On Windows OS TCP/IP sockets are handled by the Winsock API, this will differ on other OSs.
Product Specifications
| Manufacturer | Brainboxes |
|---|---|
| Manufacturer Part Number | ES-701 |
| GTIN / Barcode | 0837324009965 |
| Brand Name | Brainboxes |
| Product Name | Brainboxes Ethernet 4 Port RS232 |
| Mfr. Part Number | ES-701 |
|---|---|
| GTIN / Barcode | 0837324009965 |
| Ports & interfaces | |
| Host interface | RJ-45 |
| Host interface gender | Female |
| Output interface | RS-232 |
| Serial ports quantity | 4 |
| Serial interface type | DB9 |
| Design | |
| Internal | No |
| Product colour | Black |
| LED indicators | Status |
| Certification | EMC CE, WEEE, TAA, AEO C-TPAT |
| Features | |
| Data transfer rate (max) | 0.1 Gbit/s |
| FIFO (First In, First Out) | 2048 B |
| Flow control support | Yes |
| Export Control Classification Number (ECCN) | 5A991.b |
| Power | |
| Power consumption (typical) | 1.35 W |
| Power supply input voltage | 5 - 30 V |
| External power adapter | Yes |
| System requirements | |
| Windows operating systems supported | Yes |
| Technical details | |
| Compliance certificates | RoHS |
| Weight & dimensions | |
| Width | 135 mm |
| Depth | 300 mm |
| Height | 80 mm |
| Weight | 959 g |
| Packaging data | |
| Quick installation guide | Yes |
| Package width | 240 mm |
| Package depth | 260 mm |
| Package height | 80 mm |
| Package weight | 1.05 kg |
| Logistics data | |
| Harmonized System (HS) code | 851762 |
| Other features | |
| Connectivity technology | Wired |
| Mac compatibility | No |
| Ethernet LAN (RJ-45) ports | 1 |
| Brand | Brainboxes |
| Availability | In Stock |
| Price Currency | CAD |
| Category | Networking & Communications |
