Brainboxes
Brainboxes USB RS422/485 8 WAY HUB US-601
CA$392.99
Save 5%
CA$373.88
CAD
Prices shown in CAD. Taxes, duties and freight are quoted separately. Call 888-370-2261 for volume pricing.
- B2B Volume Pricing in CAD
- Purchase Orders Accepted for Approved Accounts
- Canada-Wide Business & Institutional Purchasing
- Secure Checkout & Reliable Canada-Wide Delivery
Product Details
USB to Serial multi drop hub providing 1 RS422/485 serial port multiplexed 8 times for multibus applications. Data transfer rates up to 921,600 baud rates and the 128 byte deep transmit and 256 byte receive FIFOS, coupled with 1Mbit line drivers deliver uncompromising performance on your laptop/PC. Drivers for Windows 32 bit and 64 bit Operating Systems including Windows XP, Server 2003, Vista, Server 2008, Windows 7 and Windows 8 with additional drivers for both Mac OS X and Linux.
Product Specifications
| Manufacturer | Brainboxes |
|---|---|
| Manufacturer Part Number | US-601 |
| GTIN / Barcode | 0837324002706 |
| Brand Name | Brainboxes |
| Product Name | Brainboxes USB RS422/485 8 WAY HUB |
| Mfr. Part Number | US-601 |
|---|---|
| GTIN / Barcode | 0837324002706 |
| Ports & interfaces | |
| Host interface | USB Type-B |
| Host interface gender | Female |
| Output interface | Serial |
| USB 2.0 ports quantity | 1 |
| Serial ports quantity | 8 |
| Serial interface type | DB9 |
| Design | |
| Internal | No |
| Product colour | Black |
| Country of origin | United Kingdom |
| Features | |
| Baud rate | 921.6 Kbit/s |
| FIFO (First In, First Out) | 256 B |
| Data bits | 7, 8 |
| Stop bits | 1, 2 |
| Full duplex | Yes |
| Flow control support | Yes |
| Parity bit | Even, Mark, No, Odd, Space |
| Flow Control type | DTR/DSR, RTS/CTS, XON/XOFF |
| Export Control Classification Number (ECCN) | 4A994 |
| System requirements | |
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows Vista, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows Vista x64, Windows XP, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 |
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Server operating systems supported | Windows Server 2008, Windows Server 2008 x64 |
| Technical details | |
| Compliance certificates | Federal Communications Commission (FCC), CE, UKCA |
| Weight & dimensions | |
| Width | 123 mm |
| Depth | 215 mm |
| Height | 56 mm |
| Weight | 773 g |
| Packaging data | |
| Cables included | USB Type-A to USB Type-B |
| Package width | 135 mm |
| Package depth | 300 mm |
| Package height | 80 mm |
| Package weight | 965 g |
| Logistics data | |
| Harmonized System (HS) code | 84718 |
| Other features | |
| Maximum operating distance | 1200 m |
| Compatible operating systems | Windows XP/Server 2003/Vista/Server 2008/7 Mac OS X Linux |
| Brand | Brainboxes |
| Availability | In Stock |
| Price Currency | CAD |
| Category | Cables & Connectivity |
