Name: TP-Link Omada 32-Port 10GE SFP+ L2+ Managed Switch SX3032F
Brand: TP-Link
SKU: SX3032F
Price: 1250.16 CAD
Availability: InStock

888-370-2261 info@itlogixs.ca 157 Edith Way NW, Calgary, AB, T3R 2B8

Home /Networking & Communications /Transceivers & Modules /TP-Link Omada 32-Port 10GE SFP+ L2+ Managed Switch

Product Details

Omada 32-Port 10GE SFP+ L2+ Managed Switch

Easily Build a Whole 10G Multi-gigabit Network

Software Defined Networking (SDN) with Cloud Access
Remotely manage your access points, switches, and gateways across multiple sites all from a single interface.

Product Specifications

Manufacturer	TP-Link
Manufacturer Part Number	SX3032F
GTIN / Barcode	4895252504477
Brand Name	TP-Link
Product Name	TP-Link Omada 32-Port 10GE SFP+ L2+ Managed Switch

Management features
Mfr. Part Number	SX3032F
GTIN / Barcode	4895252504477
Switch type	Managed
Switch layer	L2+
Quality of Service (QoS) support	Yes
Cloud-managed	Yes
ARP inspection	Yes
Configuring Location Settings (CLI)	Yes
MIB support	• MIB II (RFC1213) • Interface MIB (RFC2233) • Ethernet Interface MIB (RFC1643) • Bridge MIB (RFC1493) • P/Q-Bridge MIB (RFC2674) • RMON MIB (RFC2819) • RMON2 MIB (RFC2021) • Radius Accounting Client MIB (RFC2620) • Radius Authentication Client MIB (RFC2618) • Remote Ping, Traceroute MIB (RFC2925) • Support TP-Link private MIB
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	1
Installed SFP+ modules quantity	32
Console port	RJ-45/Micro-USB
Network
Networking standards	IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1x, IEEE 802.3ah, IEEE 802.3x
Port mirroring	Yes
Flow control support	Yes
Link aggregation	Yes
Broadcast storm control	Yes
Rate limiting	Yes
Spanning tree protocol	Yes
IPv4 routes	48
IPv6 routes	48
VLAN support	Yes
Virtual LAN features	Protocol-based VLAN, SSID-based VLAN assignment, Tagged VLAN, VLAN mapping, Voice VLAN
Number of VLANs	30
Data transmission
Switching capacity	640 Gbit/s
Forwarding rate	240 Mpps
MAC address table	32000 entries
Number of queues	8
Static route	Yes
Number of static routes	128
Number of IP interfaces	128
Jumbo frames support	Yes
Jumbo frames	9
Packet buffer memory	24 MB
Security
DHCP features	DHCP relay, DHCP server, DHCPv6 snooping
Access Control List (ACL)	Yes
IGMP snooping	Yes
Static port security	Yes
SSH/SSL support	Yes
Loop protection	Yes
IP-MAC-Port binding	Yes
Authentication	MAC-based authentication, Port-based authentication
Password protection	Yes
Authentication type	AAA, TACACS+
Queue scheduling algorithms	Priority queuing (PQ), SP, Weighted Round Robin (WRR)
Multicast features
Multicast support	Yes
Number of multicast groups filtered	4000
Multicast Listener Discovery (MLD) snooping	Yes
Protocols
GARP VLAN Registration Protocol (GVRP)	Yes
IPv4 & IPv6 features	Dual stack IPv4/IPv6, ICMPv6, IPv6 TFTP
IP Source Guard (IPSG)	Yes
Design
Rack mounting	Yes
Product colour	Black
Redundant fans support	Yes
Number of fans	2 fan(s)
Power
Power source	AC
Power supply included	Yes
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (max)	49.4 W
Operational conditions
Operating temperature (T-T)	-5 - 45 °C
Storage temperature (T-T)	40 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 90%
Weight & dimensions
Width	440 mm
Depth	330 mm
Height	44 mm
Packaging content
Cables included	Power
Quick start guide	Yes
Certificates
Compliance certificates	CE, Federal Communications Commission (FCC), RoHS
Brand	TP-Link
Availability	In Stock
Price Currency	CAD
Category	Transceivers & Modules
